Shelly PM Mini Gen3
Shelly PM Mini Gen3 - Image 2
Shelly PM Mini Gen3 - Image 3
Shelly PM Mini Gen3 - Image 4
Shelly PM Mini Gen3 - Image 5

Shelly Smart Home

SKU: FG3800235261613

Shelly PM Mini Gen3

9.600 JOD

3 Years Manufacturer Warranty

Wi-Fi-operated smart power meter, 1 channel 16 A The smallest power meter in the world for precise power monitoring. Automate your lights or electrical appliances in less than 10 minutes and monitor their power consumption from anywhere.

Request information
  • Wi-Fi-operated smart power meter, 1 channel 16 A The smallest power meter in the world for precise power monitoring. Automate your lights or electrical appliances in less than 10 minutes and monitor their power consumption from anywhere.

Reference

Technical specifications

Every value below is sourced from the manufacturer datasheet. Engineering-first hardware, documented down to the last gram.

01

Physical

  • Size (HxWxD)
    29x34x16 ±0.5 mm / 1.11×1.34×0.63 ±0.02 in
  • Weight
    13 ±1 g / 0.46 ±0.04 oz
  • Mounting
    Wall box
  • Screw terminals max torque
    0.4 Nm / 3.5 lbin
  • Conductor cross section
    0.2 to 2.5 mm² / 24 to 14 AWG (solid, stranded, and bootlace ferrules)
  • Conductor stripped length
    6 to 7 mm / 0.24 to 0.28 in
  • Shell material
    Plastic
  • Color
    White
02

Environmental

  • Ambient temperature
    -20 °C to 40 °C / -5 °F to 105 °F
  • Humidity
    30 % to 70 % RH
  • Max. altitude
    2000 m / 6562 ft
03

Electrical

  • Power supply
    110 – 240 VAC
  • External protection
    16 A, tripping characteristic B or C,

  • 6 kA interrupting rating,

  • Energy limiting class 3
  • Power consumption
    <1.2 W
04

Output circuits ratings

  • Max measurement voltage
    240 VAC
  • Max measurement current
    16 A
  • Max measurement power
    3840 W
  • Power measurement
    Yes
  • Voltage protection / Cutoff
    No
  • Current protection / Cutoff
    No
  • Max power protection / Cutoff
    No
05

Radio

  • RF band
    2400 – 2495 MHz
  • Max. RF power
    <20 dBm
  • Wi-Fi protocol
    802.11 b/g/n
  • Wi-Fi Range
    Up to 30 m / 100 ft indoors and 50 m / 160 ft outdoors

  • (Depends on local conditions)
  • Bluetooth Protocol
    4,2
  • Bluetooth Range
    Up to 10 m / 33 ft indoors and 30 m / 100 ft outdoors

  • (Depends on local conditions)
06

MCU

  • CPU
    ESP-Shelly-C38F
  • Flash
    8 MB
07

Firmware capabilities

  • Webhooks (URL actions)
    20 with 5 URLs per hook
  • MQTT
    Yes
  • UPD
    Yes
  • Scripting
    Yes

Works with

Plays well with the platforms you already use.

Connect over Wi-Fi, Bluetooth, or Matter and control from any of the major ecosystems.

  • Amazon Alexa Voice
  • Google Home Voice
  • Apple Home iOS / iPadOS
  • Matter Standard
  • Home Assistant Open source
  • SmartThings Samsung
